THE LAW OF STORMS:

THE VARIOUS PHENOMENA BY WHICH THEIR
APPROACH CAN BE ASCERTAINED WITH
CERTAINTY, AND PRACTICAL
DIRECTIONS TO MARINERS
FOR THE AVOIDANCE
OF THEIR FURY.

COMPILED FROM VARIOUS SOURCES

BY
CAPT. JOHN ROSS.

A. ROMAN & COMPANY,

Booksellers, Publishers and Importers,
417 and 119 Montgomery Street, San Francisco.
27 HOWARD ST., NEW YORK.

1869.

Entered according to Act of Congress, in the year 1869,

By Capt. John Ross,

In the Clerk’s Office of the District Court of the United States
for the Northern District of California.

Printed by SPAULDING & BARTO,
Mining and Scientific Press Job Office,
414 Clay Street, San Francisco.

[3]

In the Northern Hemisphere, when the Polar and Equatorial currents of air are alternating with each other, the regular shifting of the wind round the compass will be through S., S.W., W., N.W., N., N.E., E., S.E., S.—and the changes will take place oftener between south and west, and between north and east, than between west and north, and between east and south.

Similarly in the Southern Hemisphere, it may be inferred that when Polar currents of air alternate with Equatorial, the regular shifting of the wind round the compass will be successive through S., S.E., E., N.E., N., N.W., W., S.W., S.

This is Dove’s “Law of Gyration,” (or the law of the rotation of winds). And collecting the main points into a few general propositions, it may be laid down, that all steady winds are modified by the rotation of the earth, in such a manner that Equatorial currents of air receive a westerly deflection, and Polar currents an easterly deflection; but latitudinal currents suffer no change. The N.E. and S.E. Trade Winds are steady Polar currents. The Monsoons are alternations of a Polar and an Equatorial current, twice during the year. Therefore they are N.E. and S.W. in the Northern Hemisphere, and S.E. and N.W. in the Southern Hemisphere. [4]

The S.W. passage winds of the Northern Hemisphere, and the N.W. passage winds of the Southern Hemisphere, are Equatorial currents.

Bodies of air set in motion from a state of rest, turn the wind-vane in the direction of the meridian as follows:

The Polar current in the Northern Hemisphere from N. to E.

The Polar current in the Southern Hemisphere from S. to E.

The Equatorial current in the Northern Hemisphere from S. to W.

The Equatorial current in the Southern Hemisphere from N. to W.

In general the winds in the Northern Hemisphere are as follows:

Those from N. to E. the Polar currents.

Those from E. to S. the transition of the Polar to the Equatorial.

Those from S. to W. the Equatorial current.

Those from W. to N. the transition of the Equatorial to the Polar.

Also, in the Southern hemisphere, the winds are as follows:

Those from S. to E. the Polar currents.

Those from E. to N. the transition of the Polar to the Equatorial.

Those from N. to W. the Equatorial current.

Those from E. to S. the transition of the Equatorial to the Polar. [5]

Thus, a complete revolution of the wind-vane in the Northern Hemisphere is therefore S.W., N.E., S. with the sun, and in the Southern Hemisphere the rotation is S.E., N.W., S., with the sun, also, in that region.

When the course of a steady wind is obstructed in such a manner as to produce a Hurricane, or Cyclone, the wind has a rotary or whirling motion (as it were, on an axis), while the storm itself has a progressive motion.

N. B.—The rotation of the wind during a hurricane, in the Northern Hemisphere, is in a direction contrary to that in which the hands of a watch move. In the Southern Hemisphere, the rotation is in the same direction as that of the hands of a watch. And hence the following shiftings of the vane: In the Northern Hemisphere, when the vortex (or center) of the storm passes to the westward of the place of observation, the rotation is S.W., N.E., S., with the sun; when the vortex passes to the eastward of the place of observation, the rotation is S.E., N.W., S., against the sun.

In the Southern Hemisphere, if the vortex passes to the westward of the place of observation, the rotation is S.E., N.W., S., with the sun.

If the vortex passes to the eastward of the place of observation, the rotation is S.W., N.E., S., against the sun. [6]

On Hurricanes or Cyclones.

Thus, in both Hemispheres, the passage of an equatorial whirlwind storm on the west side of the place of observation produces normal revolutions in accordance with the law of gyration; while, on the other hand, its passage on the east side produces anomalous revolutions contrary to the law of gyration. When the vortex of a whirlwind storm passes over the place of observation, the vane may shift from one direction to that immediately opposite to it.

Generally, if the whirlwind storm is an equatorial one in the Northern Hemisphere, it progresses from S.E. to N.W. in the Torrid Zone; it recurves at the outer edge of the N.E. trade wind, and thence moves from S.W. to N.E. But in the Southern Hemisphere an equatorial storm moves first from N.E. to S.W.; recurves at the outer edge of the S.E. trade wind, and then advances from N.W. to S.E.—bearing in mind the direction of the rotation of the wind in each hemisphere, viz: against watch hands in the Northern, but with watch hands in the Southern Hemisphere. Certain portions of the storms are characterized by certain hurricane winds, and dividing the storm by diameters drawn from the northern to the southern margin, and again from the eastern to the western margin, we find that in the Northern Hemisphere, on the northern margin, the wind will be easterly; on the eastern margin, southerly; on the southern margin, westerly; and on the western margin, northerly;—each portion of the cyclone possessing its appropriate wind.

The relations of the winds to the margin in the Southern Hemisphere, will be exactly the reverse of their relation in the Northern. Thus: It is the southern margin of the storm south of the Equator, that exhibits an easterly; the western margin a southerly; the northern margin a [7] westerly, and the eastern margin a northerly wind. Hence, each portion of the hurricane having its appropriate wind, there results, according to the law of the rotation of revolving gales, a very simple rule for determining the bearing of the center of the storm from the ship, viz: Look to the wind’s eye and set its bearing by compass, the eighth point to the right thereof when in the Northern Hemisphere; but to the left of the wind’s direction when in the Southern Hemisphere, will be the bearing of the storm’s center. Thus, in the Northern Hemisphere, from an easterly wind, which characterizes the northern margin of the storm, its center will bear south; from a northerly wind the center will bear east; from a westerly wind it will bear north, and from a southerly wind, west. But in the Southern Hemisphere, from an easterly wind, the center of the storm bears north; from a southerly wind the center bears east; from a westerly wind, south; and from a northerly wind, west.

The above rule is perfectly clear and definite; but as it is especially important to avoid the center of the storm,—its most dangerous part,—the following table shows at a glance its relative bearing in each Hemisphere. [8]

[9] The path which the axis of rotation describes is not inappropriately termed the “Axis Line.” On the “Axis Line” there is no change of wind until the center has passed, when, after a brief interval of calm, the wind springs up with great fury from the opposite quarter.

It has been remarked by Piddington, “that he who watches his barometer, watches his ship.” This invaluable instrument, if well understood, invariably announces the approach of a revolving storm; shows whether the vessel is plunging into the vortex, or if she be receding from it; and hence, by carefully noticing its indications, the disastrous consequences of a hurricane may, to a great extent, be avoided,—for the laws of its oscillations are very distinctly marked. The barometer often stands unusually high before the commencement of a cyclone, and frequently (if not always) just around the storm. And conceiving the cyclone to be divided into two parts by a diameter at right angles to its path, it may be noted that the barometer always falls during the passage of the advancing semi-circle of a revolving storm. The barometer always rises during the passage of the receding semi-circle [10] of a revolving storm. In cases of manɶuvering to take advantage of the hurricane winds, and to keep just within the verge of the storm, the barometer is of signal benefit,—it should be kept as high as possible, without losing the wind. In whatever position the ship may be, the rising of the mercury announces that the first (or dangerous) half of the storm has passed.

The barometer is a faithful guide in the zone of the Trade Winds. Its ordinary variations are so small that any deviation from its normal height requires attention. Its fluctuations are larger beyond the Tropics; but the indications are scarcely less certain if used in conjunction with the thermometer and hygrometer,—hence, more watchfulness is required on the part of the navigator; and it is of the utmost importance to have such a knowledge of the Law of Storms, of storm instruments, and of the signs of the weather, as to be able to detect the presence of a hurricane or cyclone, when as yet sky and sea betoken but little of that blind fury, during the height of which it is so difficult to guide the vessel in safety. One great advantage of such knowledge is a quick apprehension of the indications which forewarn, to make all snug in time.

The meteorological signs indicating the approach of a hurricane or cyclone, have been collected from various sources by Mr. Birt, and are enumerated and classed according as the phenomena may be presented to the external sensations of feeling, sight, or hearing.

METEOROLOGICAL SIGNS RECOGNIZED
BY THE FEELINGS.

• 1. A sultry, oppressive state of the atmosphere.
• 2. A calm.

METEOROLOGICAL SIGNS RECOGNIZED
BY THE EYE.

METEOROLOGICAL SIGNS RECOGNIZED
BY THE EAR.

THE METEOROLOGICAL PHENOMENA ACCOMPANYING
A REVOLVING STORM MAY ALSO BE
ENUMERATED THUS:

INDICATIONS OF APPROACHING OR EXISTING
HURRICANES, MANIFESTED BY THE OCEAN,
OF ESPECIAL UTILITY TO VESSELS AT
ANCHOR IN ROADSTEADS.

The area over which these rotary storms have been known to expand, varies from 30 to 40 to 1,000 miles; but while the diameter, so long as the storm is within the tropics, expands but very gradually, it suddenly increases in a remarkable manner after recurving. The rate at which they travel on their onward course also varies greatly, not only in different parts of the globe, but even in the same locality, and at the same season. Generally, however, the rapidity with which the vortex of the hurricane progresses is greater as the storm recurves on reaching the outer edge of the trade winds. Thus, the hurricane of August, 1853, traversed 6,276 English miles in about twelve days, with a mean progressive velocity of twenty-six miles per hour; but after it arrived at the Banks of Newfoundland this velocity was increased to about fifty miles per hour.

Within the area of the cyclone the moving body of air frequently attains a rotatory velocity of from seventy to one hundred miles an hour. [15]

TABLE SHOWING THE DIFFERENT MONTHS OF THE
YEAR IN WHICH HURRICANES AND CYCLONES
HAVE BEEN RECORDED IN VARIOUS REGIONS.

From this table it appears that the hurricane seasons in the several localities are as follows:

RULES FOR TRIMMING THE SHIP IN A HURRICANE.

Piddington long ago said: “That all positive rules tend to mislead.” Every ship must have its own peculiar management depending on the four great elements of the problem, which are—

• 1. The ship and her sea room.
• 2. The track of the cyclone.
• 3. Its rate of traveling.
• 4. The ship’s run and drift.

While, on the part of the commander, caution and watchfulness are essentially requisite, still all the circumstances being favorable, rules may be given in a very brief compass for trimming a vessel to the hurricane winds. These are embodied in the following tables. Where the directions of the wind vane, as set down in the first column are tangents to the whirlwind in its course, these indicate the quarter from which the storm sets in. The points of the compass in the second [17] column show the position of the storm’s center as regards the vessel. The fourth column gives the direction in which to steer when the wind shifts as indicated in the third column; but if it shifts as indicated in the fifth column, then bear away as told in the sixth column.

I.—FOR THE NORTHERN HEMISPHERE.

Transcriber’s Note:
† † † † † stands for:
“Put the ship on the Starboard Tack.”
Printed vertically in 6th col. (no column header) [18]

II.—FOR THE SOUTHERN HEMISPHERE.

Transcriber’s Note:
† † † † † stands for:
“Put the ship on the Starboard Tack.”
Printed vertically in 6th col. (no column header)

ADMIRAL FITZROY’S INSTRUCTIONS ON THE USE
OF THE BAROMETER IN NORTH LATITUDE.

The Barometer Rises:

For northerly wind (including from N. W. by the north to the eastward), for dry, or less wet weather, for less wind, or for more than one of these changes—except on a few occasions when rain (or snow) comes from the northward, with strong wind. [19]

A Thermometer Falls:

For change of wind towards any of the above directions.

The Barometer Falls:

For southerly wind (including from S. E. by the south to the westward) for wet weather, for stronger wind, or for more than one of these changes—except on a few occasions when moderate wind with rain (or snow) comes from the northward.

A Thermometer Rises:

For change of wind towards the upper directions only. Moisture or dampness in the air (shown by a hygrometer) increases before or with rain, fog or dew.

In south latitudes substitute south or southward for north, northward, etc.
